Hohner encoders are a type of rotary encoder that provides digital output to indicate the position of a shaft. It is available in different types to meet various industrial and commercial needs. Here are some of the types of Hohner encoders:
Absolute Encoder
This encoder provides a unique and specific value for each position. It indicates the position accurately even if there is a power loss. The output will be in binary, Gray code, or BCD. The absolute encoder is available in single-turn and multi-turn types.
Incremental Encoder
This encoder produces output in the form of quadrature signals. It calculates the position by keeping track of the pulses generated with each rotation. It is simple and cost-effective. This encoder has a multi-turn and single-turn type.
Optical Encoder
This encoder uses a light source and a photodetector to determine the position of the rotating disk. It is accurate and commonly used in applications where precision is required.
Magnetic Encoder
This encoder uses a magnet and a sensor to determine the position. It is durable and can be used in harsh environments. It is also less sensitive to dirt, dust, and debris.
Capacitive Encoder
This encoder uses capacitors to detect the position of a moving element. It is resistant to environmental factors like temperature changes and can provide high resolution.
Linear Encoder
These encoders are used for linear motion applications. It can be magnetic, optical, or capacitive. They provide information about the linear position and are mostly used in CNC machines and sliding doors.
Hohner Encoder
This is a specific type of encoder designed and manufactured by Hohner. It includes a variety of encoders such as optical, magnetic, and capacitive encoders. These encoders are known for high accuracy, robustness, and reliability in industrial applications.
Smart Encoder
This is a modern type of encoder that provides advanced features. It comes with built-in processing, communication interfaces, and error detection. It is useful for automated systems and can be integrated easily into different setups.
Every Hohner encoder has an output in accordance with the following features:
Gray code or binary code
Relative encoders can provide digital output in binary or gray code. The binary code is more straightforward but can have more errors during transitions. The gray code changes one digit at a time, which reduces errors and is useful for applications needing high reliability.
Quadrature output
Many relative encoders output two signals, A and B, that are out of phase by 90 degrees. This is called quadrature encoding, which helps determine the direction of rotation. The encoder produces different sequences for clockwise or counterclockwise movement.
Single or multi-turn
Some encoders can track rotations over multiple turns, called multi-turn encoders. They use gears and sensors to count turns and provide absolute position. Single-turn encoders only track one turn and reset each time they stop.
Incremental output
Incremental encoders output pulses each time the shaft turns a small amount. The system counts these pulses to track movement. This output can vary depending on the settings.
Digital or analog voltage output
Some encoders give a digital signal that represents the position as a number. Others output an analog voltage that changes smoothly as the shaft turns. Both types can be digital or analog.
Line driver output
Higher speed encoders use line driver outputs, which are differential signals. They send the signals farther without losing accuracy. Line drivers are good for long cables and fast movements.
Zero reset
Most encoders can be reset to zero at any position. This sets a new reference point. The encoder will then count from that spot. This is helpful to start measuring from a different point.
IP-rated
Encoders have different ratings for protection against dust and water. The industrial rating shows it can withstand tough conditions like dirt or moisture. The IP rating specifies the level of protection.
The Hohner encoder is widely applicable in different industries and scenarios. Some of the industries and scenarios include:
When choosing the right encoder, it is important to consider various factors to ensure the selected device meets the application requirements. Here are some basics one should consider before purchasing an encoder.
Determining the Encoder Type
Start by considering the application requirements. For applications that require precise positioning, a absolute encoder may be more suitable. Consider whether the application involves continuous rotation or requires discrete positioning. If continuous rotation is needed, a incremental encoder may be appropriate.
Defining Performance Specifications
Consider factors such as accuracy, resolution, and response time. Determine the required level of accuracy and resolution for the application. Higher accuracy and resolution may require more sophisticated encoders.
Considering Environmental Factors
Choose an encoder that can withstand the environmental conditions in which it will be used. If the encoder will be used in a harsh environment with dust, moisture, or extreme temperatures, consider a rugged encoder with appropriate sealing and temperature ranges.
Evaluating Communication Interface and Compatibility
Ensure that the chosen encoder is compatible with the existing control system and can communicate effectively. Different encoders use communication protocols like SSI, RS-422, SPI, or CANopen.
Assessing Mounting and Installation Requirements
Consider the available space and mounting options. Determine the best mounting method (shaft mounting or flange mounting) and installation parameters to facilitate integration.
Budgetary Considerations
While performance should be the primary concern, it is also important to consider the budget. Balance the required features and specifications with the available budget to find a suitable encoder that meets both performance and cost requirements.
Consulting with Experts
If there is uncertainty about the best encoder for a specific application, consider consulting with encoder specialists or manufacturers. They can provide valuable insights and recommendations based on their expertise and experience.
Q1. What Are The Differences Between Absolute And Incremental Encoders?
A1. Absolute encoders provide a unique digital output for each position, which corresponds to the specific position of the shaft. They have multi-turn designs that use battery backups and capacitors to retain data and prevent position loss during power outages. Absolute encoders are preferred when position accuracy and reliability during power interruptions are critical.
On the other hand, incremental encoders produce a unique output every time the shaft turns. They need to be reset and track movement, so a single turn output must be stored if the system requires a digital value. They are more cost-effective and simpler to implement in applications where tracking motion and cost efficiency are priorities.
Q2. How Does An Hohner Encoder Work?
A2. Hohner encoders work by converting the rotational movement into electrical signals. They detect the rotation and generate signals that are processed to determine the position, direction, and speed of the rotation.
Q3. What Is The Accuracy Of Hohner Encoders?
A3. The accuracy of Hohner encoders varies depending on the type. Hohner optical encoders provide high accuracy and precision. The accuracy can be as high as 0.01 degrees or better. Hohner magnetic encoders are also accurate, with typical accuracy around 0.1 degrees. Hohner capacitive encoders have very high accuracy, with accuracy of up to 0.001 degrees. Hohner resolvers provide reliable accuracy, which can be up to 1 degree.
Q4. What Factors Should Be Considered When Choosing An Encoder?
A4. The factors to consider when choosing an encoder include the application requirements, the resolution and accuracy needed, the environmental conditions, and the budget.
Q5. What Is The Resolution Of An Encoder?
A5. The resolution of an encoder refers to the number of unique output signals per revolution. It indicates the level of detail and accuracy with which the position or speed can be determined. A higher resolution means more accuracy.
